Metal Stamping Services
Custom Metal Stamping Solutions for Small to Medium-Sized Components
Finding the right metal stamping partner means choosing a manufacturer with the flexibility to produce parts efficiently, accurately, and consistently. Our metal stamping services are supported by a range of stamping press capacities, allowing us to manufacture custom metal components for a wide variety of applications and production volumes.
Whether you need prototype quantities, short production runs, or ongoing manufacturing, our team can help determine the right stamping solution for your project.
Based in Florence, AL, Tri-State Metals provides metal stamping production support to manufacturers throughout Northwest Alabama, Southern Tennessee, and Northeast Mississippi.
Versatile Metal Stamping Capabilities
Our fleet of metal stamping presses allows us to produce small and medium-sized stamped components in a variety of materials and thicknesses. By utilizing multiple press sizes, we can match the equipment to your project, helping improve efficiency while maintaining quality and repeatability.
Our Capabilities Include:
Each project is evaluated based on part geometry, material, tolerances, and production requirements to determine the most effective manufacturing process.
Materials We Stamp
We manufacture stamped components using a variety of materials, including:
Our team works with customers to identify the best material and manufacturing approach for each application.
The Komatsu OBS-60 is a 60-metric-ton (66 US ton) single-crank gap frame stamping press. Widely used for progressive and manual die operations, it features a plunger-guided slide that extendsdie life and a maintenance-free wet clutch.
Komatsu OBS-60 Specifications | |||
|---|---|---|---|
Capacity | 60 Metric Tons | Shut Height | 4.72" |
Stroke Length | 16.93" (on bed) / 11.8" (on bolster) | Slide Adjustment | 2.76" (motorized) |
Speed | 60 to 120 Strokes Per Minute (SPM) (Varies slightly by specific | Bed Area | 35.4" Left-to-Right × 21.7" Front-to-Back |
Slide Area | 19.7" Left-to-Right × 15.7" Front-to- | Approximate Weight | 11,000 to 20,000 lbs depending on the |
The Komatsu OBS-80 is a 80-metric-ton (88 US ton) stamping machine—most commonly found in the OBS (OBI single-crank) and H1F series—is a rigid gap-frame press favored for heavy-duty blanking, piercing, and forming.
Komatsu OBS-80 Specifications | |||
|---|---|---|---|
Capacity | 80 metric tons | Slide Area (RAM) | 34" x 24" |
Strokes | 30 to 60 Strokes Per Minute (SPM) | Opening in Back | 26" |
Bed Area | 50" (Left to Right) x 30" (Front to Back) | Floor to Bed Height | 40" |
The Verson 150-O.B.G. (Open Back Gap) is a robust 150-ton mechanical metal stamping press. It is highly prized for its large bed space and heavy-duty capabilities, making it ideal for blanking, piercing, and deep-drawing operations.
Verson 150-O.B.G. Specifications | |||
|---|---|---|---|
Capacity | 150 Tons | Bed Area | 50" Left to Right x 30" Front to Back |
Stroke Length | Typically 8" to 12" depending on the | Slide Area (RAM) | 34" x 24" |
Shut Height | 22" (from bed to slide, adjustment up) | Opening in Back | 26" |
Slide (RAM) Adjustment | 6" (motorized/powered) | Floor to Bed Height | 40" |
Speed | 30 to 60 Strokes Per Minute (SPM) | Motor | 15 HP motor |
The Rouselle #6 Mechanical Punch Press is a 60 Ton X 4” Gap Frame OBI Single Crank Mechanical Punch Press with Air Clutch and Brake, One Shot Lube System
Rouselle #6 Mechanical Punch Press Specifications | |||
|---|---|---|---|
Capacity | 60 Tons | Bed Width | 18" |
Strokes | 4" | Bed Length | 30" |
Shut Height | 11.5" | Speed | 110 Strokes/min. |
Flexible Manufacturing for a Wide Range of Industries
Our metal stamping capabilities support manufacturers across numerous industries, including:
Whether your project requires a simple stamped bracket or a complex formed component, we have the flexibility to support a wide range of manufacturing needs.
Quality You Can Depend On
Consistent quality starts with the right equipment and experienced manufacturing processes. We focus on producing stamped components that meet customer specifications while maintaining efficiency throughout production.
From initial review through final production, our goal is to provide dependable service, clear communication, and quality workmanship on every project.
A Manufacturing Partner for
Every Project
With multiple press sizes and flexible production capabilities, we can match the right equipment to your part requirements. This allows us to support everything from smaller precision stampings to larger production components while providing responsive service and competitive lead times.
If your project requires additional manufacturing processes, we can also support value-added operations such as fabrication, machining, welding, and assembly to help simplify your supply chain.
Request a Quote for Metal Stamping Services
If you're looking for a reliable manufacturer offering custom metal stamping services, our team is ready to help. Contact us today to discuss your project requirements, production volumes, and material specifications. We'll work with you to develop a stamping solution that fits your needs.
